MERCURY IN STEEL DISTANCE TYPE TEMPERATURE GAUGE

Ref. Standard: EN 13190
Dial Size: 100. 150 mm
Accuracy: ± 1%
Bourdon Tube: SS 316L
Connection Material: SS 316
Gear Mechanism: SS 304
Case :SS 304 with Bayonet Bezel as a standard (SS 316 Optional) / Die cast aluminum
Protection: Weatherproof to IP-67 (IS/IEC 60947 Part I)
Process Connection: 3/8.1/2. BSP & NPT Male. M 20 X 1.5 (Adjustable length 300 mm max)
Dial: Aluminum white background with black letters
Pointer: Micrometer zero adjustable (Black Aluminum)
Capillary: SS 304 Sheath (SS 304 Armour & PVC cover Optional)
Capillary length: 3 metre std.(upto 30 metre)
Bulb / Stem Dia: 12/9. 10/9 & 8/8
Bulb / Stem Material: SS 316
Window: Plain / Toughened /Shatter Proof glass
Mounting: Projection or Surface with bottom! Panel with back entry
Over range: 130% (FSD)
Optional: Glycerine Filled. Electric Contact
Accessories: Thermowell
